Product Description

Bushliner Cyclone Homebuilt Experimental | Model 1850-EX | Fuel Capacity 140 Gallon | Heavy-Duty Gear-Boxes

Description

The Bushliner Cyclone 1850EX Homebuilt Experimental is designed for enthusiasts who appreciate the satisfaction of building their own aircraft. This homebuilt kit comes with advanced features and modern performance, making it an exceptional choice for aviation hobbyists.

Key Features

Airframe:
- New Wide-Body Fuselage: Made of 2024t3 clad aluminum for durability and strength.
- Heavy-Duty Gearboxes & Seaplane Kit: Installed for enhanced performance.
- Skins Primed Prior to Assembly: Ensuring longevity and protection.
Cabin & Cargo:
- Upward opening cabin doors.
- 30” x 48” wide cargo door.
- Extra large 10’ long cargo bay with a flat floor and tie downs.
Seats:
- JAARS S-Frame Inertia Absorbing Pilot and second row seats rated for up to 30G of impact.
Windshield:
- Solar-Gray UV-protected windshield for comfort and protection.
Controls:
- Dual yokes and rudder pedals for better maneuverability.
Baggage Area:
- Extended 10’ baggage area for ample storage.
Seating Capacity:
- - Accommodates 2-6 passengers.
Performance:
- Extended Wings: With aerodynamic enhancements, total wingspan of 38’6” (including a 1’ extension inboard of the strut).
- Fuel Capacity: 140-gallon total fuel capacity for extended range.
Sportsman STOL and Vortex Generators: Included for improved short takeoff and landing performance.
Landing Lights: Provisions for landing lights in both wing leading edges.
Materials:
- Carbon Fiber Flaps and Ailerons: Lightweight and strong.
- Manual 40º of flaps for precise control.
- Carbon Fiber Tail and Control Surfaces: For improved performance and durability.
- Increased horizontal stabilizer width to 13’ total.
Trim and Autopilot:
- Trimmable Horizontal Stab: Using McFarlane Jack screws.
- Electric Horizontal Stab Pitch Trim: Coupled to the Garmin GFC500 autopilot.
- Elevator Pitch Control & Yaw Damper: When coupled to the Garmin GFC500 autopilot.
- Autopilot & Pitch Trim Servo: Required but not included.

Detailed Specifications

Dimensions

Specification	Bushliner 1850 Cyclone EST	Cessna A185F Skywagon	Cessna 182T Skylane	Cessna T206H Stationair
Length	26 ft	25 ft 9 in	29 ft	28 ft 3 in
Height	8 ft	7 ft 9 in	9 ft 4 in	9 ft 4 in
Wingspan	38 ft	36 ft	36 ft	36 ft
Wing Area	186 sq ft	174 sq ft	174 sq ft	174 sq ft
Flap Area	21.5 sq ft	21 sq ft	34 sq ft	-
Aileron Area	17.85 sq ft	17.85 sq ft	17.85 sq ft	14.75 sq ft
Horizontal Stabilizer Width	13 ft	10 ft 10 in	11 ft 8 in	13 ft
Horizontal Stabilizer SQFT	36 sq ft	30 sq ft	33 sq ft	36 sq ft
Tail Area % of Wing Area	19.35%	17.24%	18.96%	20.70%

Interior

Specification	Bushliner 1850 Cyclone EST	Cessna A185F Skywagon	Cessna 182T Skylane	Cessna T206H Stationair
Height	50 in	48 in	49 in	50 in
Shoulder Width	45 in	40 in	42 in	44 in
Center Seat Spread (Yoke)	21 in	18 in	19 in	21 in
Length	11 ft 8 in (flat)	11 ft 8 in (stepped)	11 ft 2 in (stepped)	12 ft 1 in (stepped)
Maximum Passengers	4 Special Light Sport	6	4	6

Weights

Specification	Bushliner 1850 Cyclone EST	Cessna A185F Skywagon	Cessna 182T Skylane	Cessna T206H Stationair
Maximum Ramp Weight	3,600 lb	3,350 lb	3,110 lb	3,806 lb
Maximum Takeoff Weight (Gross)	3,600 lb	3,350 lb	3,110 lb	3,789 lb
Maximum Landing Weight	3,600 lb	3,350 lb	2,950 lb	3,600 lb
Usable Fuel Weight (100LL)	672 lb	504 lb	522 lb	522 lb
Usable Fuel Volume	112 gal	84 gal	87 gal	87 gal
Basic Empty Weight	1,850 lb	1,850 lb	2,000 lb	2,365 lb
Useful Load	1,750 lb	1,500 lb	1,110 lb	1,441 lb
Full Fuel Payload	1,078 lb	996 lb	588 lb	919 lb
Wing Loading @ Gross Weight	19.35 lb/sqft	19.3 lb/sqft	17.8 lb/sqft	20.7 lb/sqft

Performance

Specification	Bushliner 1850 Cyclone EST	Cessna A185F Skywagon	Cessna 182T Skylane	Cessna T206H Stationair
Max Endurance Range	1,042 nm	721 nm	930 nm	660 nm
Max Speed Range	752 nm	576 nm	773 nm	632 nm
Takeoff Distance	1,200 ft	1,365 ft	1,514 ft	1,970 ft
Ground Roll	650 ft	770 ft	795 ft	1,060 ft
Landing Distance	1,200 ft	1,400 ft	1,350 ft	1,395 ft
Ground Roll	480 ft	480 ft	590 ft	735 ft
Service Ceiling	19,000 ft	17,150 ft	18,100 ft	26,000 ft
Maximum Climb Rate	1,500 fpm	1,010 fpm	924 fpm	960 fpm
Maximum Limit Speed	175 kias (201 mph)	155 kias (178 mph)	175 kias (201 mph)	182 kias (209 mph)
Stall Speed	40 kcas (46 mph)	49 kcas (56 mph)	49 kcas (56 mph)	57 kcas (66 mph)
Maximum Cruise Speed	165 ktas (190 mph)	145 ktas (167 mph)	165 ktas (190 mph)	161 ktas (185 mph)
Power to Weight	11.42 lb/hp	11.17 lb/hp	13.5 lb/hp	11.6 lb/hp
Cruise Speed @ 75% 10,000 ft	150 kt (172 mph)	130 kt (150 mph)	145 kt (166 mph)	150 kt (172 mph)
Fuel Burn @ 75% Power	18 gph 100LL	15.6 gph 100LL	17.8 gph 100LL	19 gph 100LL

Powerplant

Specification	Bushliner 1850 Cyclone EST	Cessna A185F Skywagon	Cessna 182T Skylane	Cessna T206H Stationair
Manufacturer	Lycoming	Continental	Lycoming	Lycoming
Model	IO-580	IO-520D	IO-540-AB1A5	TIO-540-AJ1A
Power Output	315 hp	300 hp	230 hp (235 hp)	310 hp (310 hp)
Propeller Manufacturer	MT Propeller	McCauley	McCauley	McCauley
Description	3 blade composite cs	2 blade aluminum cs	3 blade aluminum cs	3 blade aluminum cs

Cargo Capacity

Specification	Bushliner 1850 Cyclone EST	Cessna A185F Skywagon	Cessna 182T Skylane	Cessna T206H Stationair
Weight	200 lb	170 lb	200 lb	180 lb
Volume	34.8 cu ft	24.75 cu ft	32 cu ft	11 cu ft (39 cu ft total)
Cargo Door Dimension W x H	49 in x 36 in (aft 26")	15.25 in X 22 in	15.25 in X 22 in	43 in x 39 in
